SV61436 Rev. B 10-3

DM500™ and DM550™ Digital Mailing System Operating Guide

Envelope Sealing Problems

Description Possible Causes Solution

Envelope(s) not sealing

or not sealing properly

Envelope flap dimensions are not

within the acceptable range.

Use envelopes with flap depths between 1"

and 3" (25.4 mm and 76.2 mm).

Flap Depth
